Ferrite Limpet Pot Magnets with Removable Hook | Ø46mm–66mm | 6kg–25kg Pull Force

Eclipse Magnetics Ferrite Limpet Pot Magnets with Removable Hooks provide a practical and cost-effective magnetic hanging solution for industrial, retail, workshop and construction applications.

Each unit combines a ferrite magnetic core with a mild steel pot, helping to concentrate the magnetic field through the working face for improved holding performance on suitable ferrous surfaces.

The range includes three sizes from 46mm to 66mm diameter, with pull forces from 6kg to 25kg. All models are supplied with a removable M6 threaded hook, allowing items to be suspended securely while also giving the flexibility to remove or replace the hook when required.

These magnets are well suited to temporary hanging, suspension and positioning tasks involving signage, lightweight equipment, fixtures and general workshop items. Their reusable design makes them easy to reposition without the need for drilling or adhesive mounting.

With a maximum operating temperature of 120°C, Ferrite Limpet Pot Magnets offer a durable and economical alternative to higher-strength neodymium hook magnets where moderate holding force is sufficient.

Key Features

• Ferrite magnetic core for dependable holding performance
• Mild steel pot helps concentrate the magnetic field at the working face
• Available in 46mm, 56mm and 66mm diameters
• Pull forces from 6kg up to 25kg
• Removable M6 threaded hook across the range
• Suitable for temporary hanging, suspension and positioning applications
• Reusable and easy to reposition on ferrous surfaces
• Cost-effective alternative to neodymium hook magnets
• Suitable for industrial, retail, workshop and construction environments
• Maximum operating temperature of 120°C

Technical Data
