Armature Plates for Electromagnets | Ø25mm–100mm | M3–M10 Fixing

Eclipse Magnetics Armature Plates are ferromagnetic plates designed to improve the clamping performance of electromagnets and electro-permanent magnets by providing a smooth, effective magnetic contact surface.

They are particularly useful where no suitable ferrous surface is available, or where the existing surface is too thin, uneven or corroded to provide reliable magnetic contact. By reducing air gaps and improving the magnetic path, an armature plate helps maximise holding strength and create more consistent magnetic performance.

The range includes seven sizes from 25mm to 100mm diameter, with thicknesses from 3mm to 12mm. Each plate includes a counterbore fixing hole for flush installation, with screw sizes from M3 to M10 depending on the model.

Designed for use with both energise-to-hold and energise-to-release electromagnets, these plates are suitable for automation, access control, clamping, fixturing, machinery and general industrial holding applications.

For matching controlled magnetic holding solutions, explore our wider range of industrial electromagnets.

Key Features

• Designed to improve electromagnet holding and clamping performance
• Compatible with energise-to-hold and energise-to-release electromagnets
• High magnetic permeability helps maximise pull force
• Low remanence supports clean release after deactivation
• Ideal where the existing contact surface is thin, rusty or uneven
• Seven sizes from 25mm to 100mm diameter
• Thicknesses from 3mm to 12mm depending on model
• Counterbore fixing holes allow flush installation
• M3 to M10 fixing screws depending on plate size
• Fixing screws included
• Helps reduce air gaps and improve magnetic efficiency
• Suitable for automation, access control, clamping and fixturing applications

Technical Data
